model:HDL-MPR0310/TILE.48

Power Interface With 3CH 10A Relay is a standard panel power interface with relay channels. The power interface has an independent device ID address, including 3 10A relay channels, and adopts HDL Buspro protocol 485 Bus communication.

Tile Series Power Interface-With 3CH 10A Relay
Tile Series Power Interface-With 3CH 10A Relay
Tile Series Power Interface-With 3CH 10A Relay
Tile Series Power Interface-With 3CH 10A Relay
Tile Series Power Interface-With 3CH 10A Relay
Tile Series Power Interface-With 3CH 10A Relay

Power Interface With 3CH 10A Relay is a standard panel power interface with relay channels. The power interface has an independent device ID address, including 3 10A relay channels, and adopts HDL Buspro protocol 485 Bus communication. The relay channels can be switched on and off through the device ID address, and it can also be used as a power interface for Tile series panel. In conjunction with Tile series panel installed on the 86 wall box, it can realize the intelligent control of household lighting, curtains, fans, sockets and other electrical equipment.



Its main functions include:
■ With 3-channel 10A magnetic latching relay channel
■ With independent programming button and programming indicator
■ Short press the programming button to realize all relay channels on/off
■ Provide power and communication interface for HDL Tile series panel


Basic Parameters

Working voltage15-30V DC

Working current24mA/24V DC

Input voltageAC100-240V (50/60Hz)

Output channelHDL-MPR0310/TILE.48: 3CH, 10A/CH

CommunicationHDL Buspro

Cable diameter of Buspro terminal0.6-0.8mm

External Environment

Working temperature-5℃~45℃

Working relative humidity≤90%

Storage temperature-20℃~60℃

Storage relative humidity≤93%

Specifications

Dimensions81.4mm×81.4mm×32.4mm

Net weight99g

Housing materialIron, PC

InstallationWall box

Protection rating (Compliant with EN 60529)IP20
